Power harrows FR130
HP 120 - 270 • KW 89 - 200
cm 30 • inch 12
Basic machine
- Universal 3-point linkage Cat. 2 & 3
- Swinging arms tractor coupling
- Hydraulic system for opening and folding
- Hydraulic locking system for transport position
- Exclusive hydraulic floating system for the adaptation to soil conditions
- Central gearbox 1000 rpm
- Lateral multi-speed gearboxes
- Stone guards mounted on origin
- Monobloc tine-holder shaft hot-forged with hexagonal sockets for screws
- 2x Tines per rotor
- Special Tine system bi-directional "ZEUS" ideal for a low power absorption
- Cylindrical anti-flood tine-holder shaft
- Rear levelling clod bar PARABLOC adjustable by crank handles
- Central adjustable eradicator tine
- Adjustable side plates on springs
- Floating rear rollers mounting system
- Working depth adjustable by crank handle
- Safety front bar
- 250 cm wide during transport
- Rear lights bar
- Lateral cardan shaft with shear bolt torque limiter SB type
- Central standard cardan shaft (1”3/8 Z=6 tractor side yoke)
Variants width
| Model | Working width | Total width | Tines | Weight | |||
|---|---|---|---|---|---|---|---|
| cm | inch | cm | inch | n. | kg | lbs | |
| FR130 - 400 | 418 | 165 | 420 | 165 | 32 | 2100 | 4630 |
| FR130 - 500 | 516 | 203 | 518 | 204 | 40 | 2200 | 4850 |
| FR130 - 600 | 614 | 242 | 617 | 243 | 48 | 2390 | 5269 |
